best induction heating equipment supply for business
1. Shuimu portable induction heating machine has been strictly evaluated. The assessments include finite element stress analysis of all components, fatigue analysis, load increase analysis, etc.
2. The use of this product makes workers encounter lesser fatigue and tiredness. It greatly helps reduce the workload of workers.
3. The combination of advanced production technology and superior material can fully guaranteed the quality of this product.
MYD Proheat300 Portable Induction heater for Motor Casing Thermal Assembly|Shaft Coupling Thermal Assembly
MYD Proheat300 Portable Induction heater data:
Model | MYD-20KW | MYD-30KW | MYD-40KW |
Input voltage | 3*380V, 50/60Hz | 3*380V, 50/60Hz | 3*380V, 50/60Hz |
Input Current | 1~30A | 1~45A | 1~60A |
Output Current | 0~80A | 0~100A | 0~150A |
Output Power | 1~30KW | 1~30KW | 1~40KW |
Output Frequency | 2~15KHZ | 2~15KHZ | 2~15KHZ |
Thermocouple | K type | K type | K type |
Temperature control | Build in | Build in | Build in |
Heating Temperature | Max 300℃ | Max 300℃ | Max 300℃ |
Pipeline Diameter or equivalent | 50~1000 mm | 50~1000 mm | 50~1500 mm |
Heater Size | 650x400x600 mm | 650x400x600 mm | 650x400x600 mm |
Weight | 23 kg | 26 kg | 29 kg |
Induction Heating coil | |||
Length | 40-50 M | 40-50 M | 40-50 M |
Diameter | 13mm | 15mm | 15mm |
Working temperature | 0~35℃ | 0~35℃ | 0~35℃ |
Heating Blanket | Designed according to the job size | ||
MYD Proheat300 Portable Induction Heater accessories
No. | Item | Specifications | Quantity | Remarks |
1.1 | Induction Heater | MYD-20KW | 1 | |
1.2 | MYD-30KW | 1 | ||
1.3 | MYD-40KW | 1 | ||
2.1 | Soft cable coil | 40m | 1 | |
2.2 | 50m | 1 | ||
2.3 | 60m | 1 | ||
2.4 | 70m | 1 | ||
2.5 | Flat blanket coil | 10KW-800*260mm/ 300℃ | 4 | One heater 4coils connected |
2.6 | 20KW-1600*260mm/ 300℃ | 2 | One heater 2coils connected | |
2.7 | 40KW-2400*260mm/ 300℃ | 1 | ||
2.8 | 40KW-3200*260mm/ 300℃ | 1 | ||
2.9 | Fillet blanket coil | 10KW-800*(150+150)mm/ 300℃ | 4 | One heater 4coils connected |
2.10 | 20KW-1600*(150+150)mm/ 300℃ | 2 | One heater 2coils connected | |
2.11 | 40KW-2400*(150+150)mm/ 300℃ | 1 | ||
2.12 | 40KW-3200*(150+150)mm/ 300℃ | 1 | ||
3.1 | Thermalcouple | K 2m | 2 | |
3.2 | K 5m | 2 | ||
3.3 | K 10m | 2 | ||
3.4 | K 15m | 2 | ||
4.1 | Extend cable for coil
| 5m | 1 | |
4.2 | 10m | 1 | ||
4.3 | 15m | 1 | ||
5.1 | Insulation blanket
| 900*600*30mm | 2 | |
5.2 | 1500*600*30mm | 2 | ||
5.3 | 2000*600*30mm | 2 | ||
Re: We will design the coil according to the job shape and size. 2m cable coil left on each side. | ||||
Rapid Preheating:
u Weld Preheat
u Coating Preheat
u Thermal shrinkage
u Thermal Assembly for Turbine, Motor and Shaft Coupling
Company Features
1. Qingdao Shuimu Induction Equipment Co.,Ltd. believes that we have the ability to be a market leader in induction heating equipment . With professional production and R&D base, Qingdao Shuimu Induction Equipment Co.,Ltd. takes a lead in development of induction brazing machine .
2. Qingdao Shuimu Induction Equipment Co.,Ltd. has strong technical force and perfect processing equipment.
3. Up until now, Qingdao Shuimu Induction Equipment Co.,Ltd. has possessed an outstanding systematic ability to develop new induction forging machine products. We aim to provide you the perfect one-stop services from inquiry to after-sales. Get quote!
