high-quality induction heating equipment supply for industry
1. The production of Shuimu induction heating equipment is well controlled by the computer. The computer exactly calculates the necessary amounts of raw materials, water, etc to reduce unnecessary waste.
2. The development of the product keeps track with the current industry trends.
3. The product features an easy operation. It has a relatively simple operating system combining a powerful processing flow and provides simple operation instruction.
4. This machine has the desired motion. Various possible mechanisms are shortlisted and analyzed during the design phase, and the best mechanism is selected for its design.
MYD Proheat300 Portable Induction heater for Motor Casing Thermal Assembly|Shaft Coupling Thermal Assembly
MYD Proheat300 Portable Induction heater data:
Model | MYD-20KW | MYD-30KW | MYD-40KW |
Input voltage | 3*380V, 50/60Hz | 3*380V, 50/60Hz | 3*380V, 50/60Hz |
Input Current | 1~30A | 1~45A | 1~60A |
Output Current | 0~80A | 0~100A | 0~150A |
Output Power | 1~30KW | 1~30KW | 1~40KW |
Output Frequency | 2~15KHZ | 2~15KHZ | 2~15KHZ |
Thermocouple | K type | K type | K type |
Temperature control | Build in | Build in | Build in |
Heating Temperature | Max 300℃ | Max 300℃ | Max 300℃ |
Pipeline Diameter or equivalent | 50~1000 mm | 50~1000 mm | 50~1500 mm |
Heater Size | 650x400x600 mm | 650x400x600 mm | 650x400x600 mm |
Weight | 23 kg | 26 kg | 29 kg |
Induction Heating coil | |||
Length | 40-50 M | 40-50 M | 40-50 M |
Diameter | 13mm | 15mm | 15mm |
Working temperature | 0~35℃ | 0~35℃ | 0~35℃ |
Heating Blanket | Designed according to the job size | ||
MYD Proheat300 Portable Induction Heater accessories
No. | Item | Specifications | Quantity | Remarks |
1.1 | Induction Heater | MYD-20KW | 1 | |
1.2 | MYD-30KW | 1 | ||
1.3 | MYD-40KW | 1 | ||
2.1 | Soft cable coil | 40m | 1 | |
2.2 | 50m | 1 | ||
2.3 | 60m | 1 | ||
2.4 | 70m | 1 | ||
2.5 | Flat blanket coil | 10KW-800*260mm/ 300℃ | 4 | One heater 4coils connected |
2.6 | 20KW-1600*260mm/ 300℃ | 2 | One heater 2coils connected | |
2.7 | 40KW-2400*260mm/ 300℃ | 1 | ||
2.8 | 40KW-3200*260mm/ 300℃ | 1 | ||
2.9 | Fillet blanket coil | 10KW-800*(150+150)mm/ 300℃ | 4 | One heater 4coils connected |
2.10 | 20KW-1600*(150+150)mm/ 300℃ | 2 | One heater 2coils connected | |
2.11 | 40KW-2400*(150+150)mm/ 300℃ | 1 | ||
2.12 | 40KW-3200*(150+150)mm/ 300℃ | 1 | ||
3.1 | Thermalcouple | K 2m | 2 | |
3.2 | K 5m | 2 | ||
3.3 | K 10m | 2 | ||
3.4 | K 15m | 2 | ||
4.1 | Extend cable for coil
| 5m | 1 | |
4.2 | 10m | 1 | ||
4.3 | 15m | 1 | ||
5.1 | Insulation blanket
| 900*600*30mm | 2 | |
5.2 | 1500*600*30mm | 2 | ||
5.3 | 2000*600*30mm | 2 | ||
Re: We will design the coil according to the job shape and size. 2m cable coil left on each side. | ||||
Rapid Preheating:
u Weld Preheat
u Coating Preheat
u Thermal shrinkage
u Thermal Assembly for Turbine, Motor and Shaft Coupling
Company Features
1. Qingdao Shuimu Induction Equipment Co.,Ltd. is a large company that has grown and prospered, with a potent capability in manufacturing portable induction heater.
2. Our Qingdao Shuimu Induction Equipment Co.,Ltd. has already passed relative audit.
3. Our company bears social responsibilities. We underscore our commitment to the environment by using low-carbon packaging, positioning ourselves as an enterprise that champions sustainability.
